Product
The device is suitable for the recovery of dilute alcohol in pharmaceutical, food, light industry, chemical industry and other industries. It is also suitable for distillation of methanol and other solvents. According to the requirements of users, the device can distill the dilute alcohol about 30 ℃ to 90 ℃ - 95 ℃. The higher the precision of the finished liquor is, the reflux ratio can be increased, but the output will be reduced correspondingly. W type can also be used for distillation of methanol. W type is intermittent type, ZW type is continuous type.
model | Tower diameter | Production capacity of 30-40 ° feed | Production capacity of 60 - 80 ° feed | ||
(mm) | 90º | <95º | 90º | <95º | |
W-200 | ¢200 | 35 | 26 | 45 | 36 |
W-300 | ¢300 | 80 | 61 | 100 | 80 |
W-400 | ¢400 | 150 | 120 | 180 | 140 |
W-500 | ¢500 | 230 | 185 | 275 | 220 |
W-600 | ¢600 | 335 | 270 | 400 | 320 |
ZW-200 | ¢200 | 95 | >95º 60 | 110 | >95º 80 |
ZW-300 | ¢300 | 200 | 120 | 240 | 165 |
ZW-400 | ¢400 | 360 | 230 | 420 | 300 |
